F3 RE 10/17/22 AM RETRACTABLE TAIL-LIFT

LOAD CAPACITY *1000-1700-2200kg

F3 RE 10/17/22 AM with Aluminium Sliders, making the pricing attractive and is ideal to equip rental vehicles.

The 5 cylinder F3 RE 10/17/22 AM is a strong and compact lift, with very high performance.

Smooth hydraulic automatic tilt, high stiffness ideal to equip vehicles for customers that like high performance.

The 5 cylinders a F3RE 10/17/22 AM is available with a wide variety of versions, to suit commercial trucks above 7.5T GVW, rigids, trailers and semi-trailers.

*Platforms depth from 1333 mm to 1983 mm. **Approximate weight for tail-lift with platform width 2450 mm. Centre of gravity of the vehicle depending on the type of arm and the size of the installations on the vehicle (see assembly instructions). The above-mentioned weights are approximate and may vary according to production. Anteo reserves the right to change weights and technical specifications without prior notice. No indemnity for damages can be claimed from Anteo for changes in technical specifications and/or in weight.

Cylinders2 lift cylinders
+ 2 tilt cylinders
+ 1 automatic tilt cylinder
Tilt cylindersSingle Acting
Automatic tilt at ground levelYes, hydaulic
Platform materialAluminium
Lift arm widths (W)780 -1230 - 1520 mm
Platform depths aluminium1 fold 1483 - 1638 - 1783 mm
(max 2033)
2 folds 1333 - 1633 - 1833 mm
Platform widths aluminium2100 - 2250 - 2400 mm
(Max 2500)
Standard control unit:Unit Exterior control box with joystick, turn button
