REP CL 06 LR CANTILEVER TAIL-LIFTS WITH MANUAL OPENING

LOAD CAPACITY *600kg

The REP CL 06 LR cantilever tail-lifts with a manual opening are the ideal tail-lifts for logistic companies, vehicle rental companies and tool hire companies.

REP CL 06 LR is very light and compact. Therefore, it is suitable for smaller vehicles from 3.5 to 7 tons and pick-up.

MESH ALUMINIUM PLATFORM:

– very strong alloy
– less weight so more capacity to the vehicle
– no paint and no rust
– brilliant for the life

***2000 mm (78’’ 3/4) width available – weight 239 Kg (526 lbs). ***2300 mm (90’’) width max; decreased width available on request. Centre of gravity of the vehicle depending on the type of platform and the size of the installations on the vehicle (see assembly instructions). The above-mentioned weights are approximate and may vary according to production. Anteo reserves the right to change weights and technical specifications without prior notice. No indemnity for damages can be claimed from Anteo for changes in technical specifications and/or in weight.

Cylinders1 lift cylinder
Tilt cylindersNo
Platform openingManual
Automatic tilt at ground levelNo
Platform materialAluminium
Lift arm widths (W):610 mm
Platform widths Alu:Max 2000
Standard control unit:Exterior control box with joystick, turn button
