REP 15/1 NA TUCKAWAY TAIL-LIFTS

LOAD CAPACITY *1500kg

In order to satisfy the needs of the North- American market, Anteo has developed a new fold-away lift gate called REP 15/1 NA.

Anteo presented the new fold away lift gate at the Canada’s National Truck Show (EXPOCAM April 2015).

The new REP 15/1 NA is mounted with a 320 mm (12.5’’) heavy-duty vehicle floor extension plate behind the vehicle body, further equipped with 2 dock-bumpers with adjustable ladders. The main specifications are the same as REP 15/1 on next page.

* weight does not include rear cross member (50 Kg / 108 lbs). – ** width up to 2500 mm / 98.4” available on request. Centre of gravity of the vehicle depending on the type of platform and the size of the installations on the vehicle (see assembly instructions). The above-mentioned weights are approximate and may vary according to production. Anteo reserves the right to change weights and technical specifications without prior notice. No indemnity for damages can be claimed from Anteo for changes in technical specifications and/or in weight.

Cylinders1 lift cylinder
Tilt cylindersNo
Automatic tilt at ground levelYes, mechanical
Platform materialAluminium
Lift arm widths (W)620 mm / 24.4”
1120 mm /44.1”
(REP 15 RSG VERSION)
Platform depths aluminium1100 - 1200 - 1415 mm
43.3” - 47.2” - 55.7”
Platform widths aluminium2000 mm (Max 2300)
86.6” (Max 90.6”)
Standard control unit:Exterior control box with joystick, turn button
