F3CL 076 CANTILEVER TAIL-LIFTS

LOAD CAPACITY *750kg

The 4 cylinder F3CL 076 is a very light, strong and compact lift, with very high performance.

Smooth hydraulic automatic tilt.

High stiffness ideal to equip vehicles for customers that like high performance.

The F3CL 076 is available with a wide variety of quick-fit mounting plates, to suit most commercial vehicles and light trucks up to 7.5T GVW.

Main beam: tailor made to suit most commercial vehicles.

*Indicative weight of tail-lift supplied in the kit with rear bumper and with a 1400 mm depth platform. The weight may vary according to width. Anteo reserves the right to change weights and technical specifications without prior notice. No indemnity for damages can be claimed from Anteo for changes in technical specifications and/or in weight.

Cylinders1 lift cylinders
+ 2 tilt cylinders
+ 1 automatic tilt cylinder
Tilt cylindersSingle Acting
Platform openingSpring and gravity
Automatic tilt at ground levelYes, Hydraulic
Platform materialAluminium
Standard platform depths Alu:1400 - 1600 - 1800 mm
(max. 2000mm)
Standard platform widths Alu:2090 mm
(max 2300)
Lift arm widths (W)440 mm
Standard control unit:Exterior control box with joystick, turn button
