F3M 10 CANTILEVER TAIL-LIFTS

LOAD CAPACITY *1000kg

The 2-cylinder F3M 10 is a light compact lift with high simplicity, low maintenance cost and attractive pricing ideal to equip rental vehicles and light-duty commercial vehicles.

The F3M 10 is available with a wide variety of quick-fit mounting plates, to suit most commercial vehicles and light trucks up to 7.5T GVW.

*Indicative weight of tail-lift supplied in the kit with rear bumper and with a 1400 mm depth platform. The weight may vary according to width. Anteo reserves the right to change weights and technical specifications without prior notice. No indemnity for damages can be claimed from Anteo for changes in technical specifications and/or in weight.

Cylinders1 lift cylinder + 1 tilt cylinder
Tilt cylindersSingle Acting
Platform openingSpring and gravity
Automatic tilt at ground levelYes, mechanical
Platform materialAluminium
Lift arm widths (W)570mm
Platform depths aluminium1400*mm - 1600mm
(max 2000mm - F3M10HS)
Platform widths aluminium2180mm - 2280mm
(max 2500mm)
Standard control unit:Exterior control box with joystick, turn button
